Measurement range
Spherical power
-29.00 ~ +26.75 D (0.12 D/ 0.25 D / 1.00 D / 2.00 D / 3.00 D STEP)
Cylinder power
0.00 ~ ±8.75 D (0.25 D / 1.00 D / 2.00 / 3.00 D STEP)
Cylinder axis
0 ~ 180° (1° / 5° / 15° STEP)
PD
48 to 80mm (far), 50 to 74 mm (near)
Prism
0 to 20 ∆ (0.1 / 0.5 / 2.0 ∆ STEP)
Refractor head
Auxiliary lens
Occluder, Pinhole (Ø 2 mm), Red / green filter, Polarising filter, Fixed cross cylinder lens (±0.50 D), Red Maddox rod, Dissociation prism (3, 6, 10 ∆ )
Cross cylinder
±0.25 D, ±0.50 D, ±0.25 D auto
Retinoscopy
+1.50 D (67 cm), +2.00 D (50 cm)
Visual field
40° (VD=12mm), 39° (VD=14mm)
Level adjustment
±2.5°
PD adjustment
monocular / binocular
Near vision
Working distance
35 to 70 cm (5 cm STEP)
Near point chart illumination
LED
Dimensions & electric requirements
Phoropter head
Dimensions WDH
410 x 65 x 320 mm
Weight
approx. 4.0 kg
Phoropter arm holder
Ø 21 mm ±0.5 mm
Controller
Display
Colour TFT-LCD 10.4“ touch panel
Printer
Built-in thermal
Dimensions WDH
230 x 235 x 65 mm
Weight
approx. 3.3 kg
Input
AC 110~220V (±10%)
Power consumption
220-270 VA
